130011:110v Engraving Machine with clamp
Out Of Stock

Similar products

130035:[DISCONTINUED]110V 2030 laser engraving machine-Yellow

017025:3050 50W Laser Engraving Machine

130036:[DISCONTINUED]Mini laser machine 100mW Mini Laser engraving machine Carving tool Marking Machine Laser Painting

130057:6090 CO2 Laser Engraving Cutting Machine Engraver 60W

130062:50W laser engraving machine 3050

40W CO2 Laser Engraving Machine 20*30CM
This brand new CO2 laser engraver is suitable for various materials, such as mylar stencil material,bamboo piece, double-color planks, rubber plate,boulder, horns, leather, crystal, wood, organic plastic, abrics, paper ,film, canvas , rubber stamp material, Acrylic and Plastics. The Computerized Mini Laser Engraving and Cutting Machine is equipped with one 40W water cooling laser tube, high precise stepping motors, high quality control board.This machine employs an USB port and thus can be connected to your laptop or desktop. you can output data directly from coredraw software WinsealXP,LaserDRW Don't support MOSHI Draw.this machine can work well with multiple graphic formats including EMF/JPG/PLT/WMF.

If you are International customer out of Canada or USA, please contact with us for consulting the detailed shipping information.
We offer one year warranty for laser engraving machines except laser tube.

According to the thickness of the material, the laser head can adjust focus moved up and down, to achieve the optimal carving (cutting), range of adjustment is 0-0.25 "(1 cm)
● Certification (FDA, CE, ISO9001)
● USB Port to Computer
● CorelDRAW LASER-Software. Directly output data from CorelDraw software.Your computer should install orconfigure the CorellDraw Software.
● More Precise Stepping Motor .
● Reinforced and thickened machine body make transportation absolutely to be safer and longer life time.
● Built heat dispersed fan to reduce all electronic component's temperature
● Adopt Japan imported advanced motherboard and microchip to make engraving high speed, high accuracy,and machine long-life.
● Adopt Germany imported bearing and high accuracy stepping belt which not only make the engraving more precise, also make the machine life time twice to three times than ordinary CO2 LASER Engraver.
● Support multiple graphic formats including BMP/JPG/JPEG/WMF/EMF/PLT.
● Engrave almost anything on almost any surfacen videos.

Laser Type

CO2 Gas

Tube Trigger Volt


Tube Operating Volt


Current 0~30mA
Engraving Area 260x180mm
Maximum Item Size to Engrave 8.75"x10.25"x2.85" (22x26x7cm)
Laser Tube (life hours) 1000-1300 Hours
Laser Power 40W
Engraving Speed 0-13.8 in./s (0-350mm/s)
Cutting Speed 0-1.38 in./s (0-35mm/s)
Minimum Shaping Character 0.04 X0.04in (1mm X 1mm)
Resolution Ratio 0.001 in (0.026mm) / (1000dpi)
Power Supply 110V/60Hz for USA, Canada,Japan etc.
220V~250V for other countries all over the world.
If you need 220V~250V,please contact us.

Resetting Positioning

≤0.0004 in (0.01mm)

Motor Type Stepper Motor
Software Supported LaserDRW
Power Consumption ≤250W

Operating Temperature

32-113F (0-45C)

Graphic Format Supported


Water Cooling

Water Pump include
Recommended Spare Parts Laser Tube, Focal lens, Reflection lens
Shipping Weight 91.3Lb (41.5kg)

Package size

37.8"x25.2"x15.7" (96x64x40cm)

Explanation of the control panel :

Current regulation: using this button to adjust the electric current output.
Current Indication: mA : refers to actual output electric currnet of the engraver.
Laser switch: After pressing the button ,the laser switch be pressed before each engrave ,otherwise the laser will not shine.
Test switch: Only available for checking .
Switchboard : Master switch for controlling engraver.

Appearance and connecting directions
USB : At right side of the engraver , the port will connect relevant port on the computer through printing cable .
Air Pump port :Keep the lens clean prevent the carving material from burning。
Water-cooling pipe port : It is for the circulation of cooling water . To lengthen the service life of the laser tube , purified water is to promoted .
Fan port : At the hinder of the engraver and used for the installation of exhaust fan . The fan must be correctly installed for the cleanness of the machine .
This machine is suitable to seal engraving, advertisement, art gift, garment, leather, toy, building upholster, computerized embroidery, packing and printing, paper product, garments sampling, large width tailoring, shoemaking, furniture, industry, craftwork, nameplates decorations, woodcut and other industries.
Acrylic Sheet Engraving

Acrylic is the most popular material to engrave using a laser system. It engraves and cuts very easily, comes in a wide variety of shapes and sizes, and can be relatively inexpensive. Acrylic comes in two forms, cast and extruded.
Cast acrylic is used for almost all engraving purposes. This is because the frost produced provides a nice white contrast against the clear material.
Extruded acrylic remains clear when engraved but does not produce an adequate contrast.
However, extruded acrylic is ideal if you are going to vector cut only. Extruded acrylic is less expensive than cast and also has a lower melting point. The lower melting point produces an edge that looks flame finished when cut.

size: 600x300x3(mm)

Double-color Plate Engraving

Double-color plastic sheet is a kind of materials for engraving, which is widely applied to production of signboard, lighting advertising board, gift arts, information board, interior decoration and so on. contact us by info at our website.
The main processing way for double-color plastic sheet cover cutting, sawing, carving, gilding, laser-treating, bending and bonding.
size: 600x300x3(mm)

tags Engraving
Wood Laser Engraving
Wood engraving has been used widely in our life.
It is very easy using the laser to produce sophisticated inlay work on wood, mother-of-pearl or even plastic. Veneers may be cut to size with special accuracy using the laser.
The great advantage lies in the precision of the cut parts and also the controllability of the CAD or graphics programs.
Positive and negative parts may be cut in very thin materials without correcting the cutting width.
Mylar Airbrush Stencil Material Engraving

It's a kind of substrates to be cut by cutting plotter to form all kinds of figures and graph. The stencils are reusable, it can be used for T-shirt, wall, artwork, human body, and automotive applications. It is made of Mylar.

Thickness Size:




(The thickness of materials we provide in the package is 0.125mm ,please contact us if you need other. )

Rubber Plate Engraving
This rubber plate is made of two layers ofnatural rubber, can be cut by laser engraver to make stamp for commercial andpersonal use, especial for printing factory to print cartons and other packageboxes.
Pay attention: Please set up mirror image when carving patterns
Non-woven Fabric Engraving
Non-woven fabric is a fabric-like material made from long fibers, bonded together by chemical, mechanical, heat or solvent treatment. The term is used in the textile manufacturing industry to denote fabrics, such as felt, which are neither woven nor knitted. Nonwoven materials typically lack strength unless densified or reinforced by a backing. In recent years, nonwovens have become an alternative to polyurethane foam.
Red Rubber Stamp Material Engraving
Rubber stamping is quite simply the process of transferring and replicating an image.
Using a variety of inks and other mediums, the image on the stamp can be transferred onto a huge range of objects, transforming the ordinary into something special.
Rubber stamps have been used widely now,our laser engraving machine can make a wonderful rubber stamp,which maybe start your new business.
size about:35x4.5x4
Pay attention: Please set up mirror image when carving patterns.
Rubber Sheet for Laser Engraver Engraving?Stamp
This rubber plate with A4 size 2.3mm thicknes natural rubber, can be cut by laser engraver to make stamp for commercial and personal use.
Main features:
Smooth surface for quality results,easy cutting and engraving
Suitable for finer sized prints, having a fine ink loading, precise printing Chemical, oil, abrasion resistance
Size: 11.6"x8.26"x0.09"/297x210x2.3mm
Self-Inking Rubber Stamp Holder and Inkpad

Self-Inking Rubber Stamp works greatly and simply.We custom date, address, images and so on for you.Self Inking rubber stamp is for use in regular paper not for glossy papers.Use laser engraving machine,you can DIY all kinds of self ink rubber stamp.


1.Sturdy and durable,saving cost
2.Mark clearly,improve image
3.Convenient fuel injection,easy to carry
4.Panoramic window,precision positioning,increase efficiency
5.Custom date,address and all kinds of images to meet your needs Printing
Area: 40*15mm

Excellent Packaging
All our equipments are perfectly packaged by high-strength five-layer corrugated carton, inside withstandard soft and hard foam and three-ply board, all metal parts are separately packaged, which guarantees product safety during transportation.
Recommends Accessories :
130044: Rotary Attachment Simpler
130058: Industrial Water Chiller
130114: Industrial Water Chiller
