Packaging Supply> Labeling Machine>
160830:Round Bottle Labeling Machine
Unit:
set
Price:
970.00$
Weight:
46.00kg
QTY:


Similar products

160829:Round Bottle Labeling Machine without Code Printer

181170:MY-380F SOLID INK CODING MACHINE 110V (Widen)

Round Bottle Coding and Labeling Machine

  http://topseller365.com/data/prd/160/830/1.jpg

http://topseller365.com/data/prd/160/830/12.jpg



This machine ismade up with the semi-automatic round bottle labeling machine and thecolor ribbon hot ptinter machine.

LT-50Semi-automatic Round Bottle Labeling Machine is ideal equipment forsemi-automatic labeling of household chemicals, food and beverage, pharmaceutical, chemical, and the roundbottle in the other light industry products on the packaging. This machine is suitable for round bottles of varioussizes and the production of small quantities of many varieties. This machine can be used in stand-alone label only.

HP-241G Color ribbon coder is atable type semi-automatic machine with motor and touching control bylimit switch and with small volume,which can be suitable for matching with thevertical filling packing machine and used for printing the date of production and batch in the industries of food,beverage, medicine etc. This machine adopts hot stamp ribbon instead of liquid ink. It can print clear words on anypacking materials with the features of simple operation and convenient maintenance.



Parameters of the Labeling machine


Maximum yield of leaflet non-positioning label

50 /min

Labeling bottle diameter

Ф0.47-3.54"/Ф12-90mm

Power

50W

Power supply

110V

Use ambient temperature

5-45℃

Use relative humidity

15-90%

External dimension (length x width x height)

25.2"*13.8"*18.1"/64×35×46cm

Weight

77.2lbs/35kg


http://topseller365.com/data/prd/160/830/5.jpg


Parameters of color ribbon machine

Speed 10-260times/min, steplessspeed adjustment
Printing area Single line: max. 4×35 app. 15pcs of type
Double line: max. 8×35 app. 30 pcs of type
Third line: max.12×35 app. 45 pcs of type
Printing type Arabic numbers, Englishletters and Chinese characters
Hot stamp ribbon Standard width 1.4"/35mm, length 3.9"/100mm, coil diameter Φ10"/25.4mm, color selectable
Power 110V/60Hz, 150W
Size 10"*8.9"*12.4"/25.5×22.5×31.5cm
Weight 17.6lbs/8kg
Motor Reducer motor: 20W. 220V,rotation speed 280turn/min
http://topseller365.com/data/prd/160/830/16.jpg
Feeder Parameters


Feeding speed

118.1"-590.6"/min(3-15m/min)

Labeling accuracy

±0.5mm

Minimum label length

0.4"/1cm


Details
http://topseller365.com/data/prd/160/830/18.jpg
http://topseller365.com/data/prd/160/830/14.jpg
http://topseller365.com/data/prd/160/830/13.jpg
Item Included:
  • Semi-automatic Round BottleLabeling Machine *1
  • Color ribbon coder *1
  • Power grid *1
  • Fuse *1
  • Slotted screwdriver *1
  • Inner hexagonal wrench *1
  • Manual *1
  • Certificate of quality *1
Item Number: 160830

You can make order with no worries.
Any concerns just feel free to let us know, we'll reply in 24 hours in normal condition.
Handling Time: Shipping is usually made in 1-3 business days after payments cleared. Orders are processed from Monday-Friday; Not on the weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
We stand behind our products all the item, so even if your warranty period has expired, you can still seek for service or technical support from us with low cost.
